Foxflash ECU programmer is able to read, write and do auto checksum for MINI BMW EDC17C50 engine ECU on bench. It's important to connect device and ECU according to the Pinout diagram strictly. Check more details below.
Foxflash BMW EDC17C50 ECU Pinout diagram:
Red: +12 V (Pin1, 18)
Black: Ground (Pin 2)
Blue: CAN-H (Pin 56)
Orange: CAN- L (Pin 55)
White: Pin 92, Pin 89, Pin 9
Brown: Pin 89, Pin 92
Connect the multi-function cable correctly. There are 3 different types of hardware versions for this ECU. Try the above combinations in series. The ECU will not suffer any damage during connection tests.
Connect Foxflash ECU Tool and BMW ECU via bench box and multifunction cables
Run Foxflash Manager and Foxflash software
Select BENCH MODE>> MINI>> TC1797-BMW>> EDC17C50
Connect ECU, read ECU-OK
Read Int Flash Micro and save the data-OK
Read EEPROM and save the data- OK
All work perfectly!
Some related Foxflash FAQs:
Q1: If you doing an ECU cloning, do you read both flash data and EEPROM and do write all??
A: Yes, for cloning service you need to read Flash and EEPROM from the original ECU and write both files in the replacement ECU.
Q2: Works well with windows 7?
A: Yes, works well in Win7, sometimes lost driver but could be from antivirus.
Q3: Can foxflash read and write Isn for bmw ecus?
A: FoxFlash read/write data but not extract ISN.
Q4: If i want to clone bmw ecu i need also another tool for that? If only cloning dme with foxflash it aint working in the car?
A: For cloning ECU's FoxFlash ECU Chip Tuning Tool is enough only for part numbers from FoxFlash ECU& TCU Support List.
