OBDSTAR DC706 Clone Ford BCM TEMIC MC9S12XD256 on Bench

 OBDSTAR DC706 is able to read and write EEPROM and Flash data on Ford TEMIC MC9S12XD256 BCM in bench mode perfectly.

Device and BCM required:

OBDSTAR P004 ECU Clone Jumper

OBDSTAR P004 Adapter

OBDSTAR DC706 ECU Tool

Main cable

Ford TEMIC MC9S12XD256 BCM

Operation guide:

Keep DC706 charging and communicating throughout the whole progress

Make sure the network connection is normal as well

Select ECU Flasher>> BODY/CHASSIS/OTHER>> newest software version>> BRAND>> FORD

Input xd256 in the search box to quickly obtain the BCM model- FORD BCM TEMIC MC9S12XD256 (BENCH)

Check the Pinout and follow it to connect DC706, P004 Adapter and Ford BCM via P004 ECU Clone Jumper and main cable correctly

Turn on the power of P004 adapter

Enter the main operation interface

First connect ECU

Then read and save INT eeprom and flash (MC9S12XD256) data separately

After that, connect DC706 to a new BCM, and select the corresponding original file to write into the new Ford BCM

All read and write operations are completed.

Disconnect ECU

OBDSTAR DC706 clone Ford TEMIC MC9S12XD256 BCM on bench successfully.

FYI…

Here is the newest OBDSTAR DC706 Support List for Ford BCM/ BSI/ DDM/ KVM/ PDM/ Radio.
