How to test VVDI BE Key Pro frequencey


Had good successs with frequency test of VVDI BE key pro improved version, frequency between 315Mhz and 433Mhz, tested with and without VVDI Mercedes software

This is how to test VVDI BE Key Pro frequencey…

For those have no VVDI MB:
You can change key frequency 315 MHZ or 433MHZ with removal of a PCB resistor

Put the VVDI BE Key to the VVDI MB BGA TOOL to test the key frequency

vvdi-be-key-pro-2 vvdi-be-key-pro-3
This is a complete new BE key unused.
Test the frequency with VVDI key tool, it is 315MHZ.
Here is a square resistor marked with “FRE”, just remove it.
vvdi-be-key-pro-4
Put the BE key into the VVDI key tool to read out 433MHZ frequency.

For those have VVDI MB TOOL:
You can change key frequency 315 MHZ or 433MHZ with VVDI MB tool


Open VVDI MB tool, Enter Menu -> Other functions -> reset key frequency.
Click on ” Read out key frequency”, the result is 315MHZ.
Put the VVDI BE key on the top of the VVDI KEY TOOL and the key frequency is 315MHZ.
Insert the VVDI BE key into VVDI MB tool.
Choose” 433MHZ” then “Change key frequency”, reset successfully.
Put the VVDI BE key on the top of the VVDI KEY TOOL and read out 433MHZ.93.
Insert the VVDI BE key into VVDI MB tool and you can see ” the key frequency is 433MHZ.93″, click “OK” to confirm.
Explanation to the option “through PCB resistor”. who don’t have VVDI MB tool, then change the key frequency through PCB resistor.
http://blog.obdexpress.co.uk/2018/01/08/vvdi-be-key-pro-frequencey-test-withwithout-vvdi-mb-tool/
